6-Inch Smart Control Host with Zigbee Gateway & Tuya

Features:

With high-transparency crystal panel and high sensitivity 6-inch touch screen
Adopt Bluetooth wireless connection technology
Standard 86 mounting box mounted on the wall for easy control
With RJ45 network interface
With Tuya ZIGBEE gateway and relay
RS485 integration with third party system
Support Tuya APP for smart home control.
Support smart home control: air conditioning temperature, curtain opening and closing, light color, light brightness and volume.
Suitable for hotels, villa, homes, commercial areas, kid’s room, etc.l.

Model	B6-ADT2	B6-25ADT
Output Power	/	2*25W
Speaker Impedance	/	4-8ohm
System	Android 8.1	Android 8.1
RAM	2G	2G
ROM	8G	8G
Network	WIFI	WIFI
Display	6-inch capacitive touch screen	6-inch capacitive touch screen
Resolution	1440*720 IPS	1440*720 IPS
Bluetooth Wireless Range	10M	10M
SNR	≥98dB	>98dB
Frequency Response	20Hz-20KHz	20Hz-20KHz
Music format	MP3,WAV,WMA,FLAC,APE,,ACC,AC3,OGG	MP3,WAV,WMA,FLAC,APE,,ACC,AC3,OGG
Video format	MPEG1/2/3/4,RM/RMVB,WMV,MOV,MK,VOB,AVI,3GP,H,264	MPEG1/2/3/4,RM/RMVB,WMV,MOV,MK,VOB,AVI,3GP,H,264
Power Requirements	AC 110-250V	AC 110-250V
Color	Black	Black
Product Dimension	208x86x11.5mm	208x86x11mm
Net Weight	0.45kg	0.45kg
